A2FM Axial Piston Fixed Motor
The A2FM bent-axis axial piston motor is designed for open and closed hydrostatic transmission systems in mobile and industrial applications. Speed is proportional to input flow, while torque increases with pressure differential. With a wide displacement range, it easily matches different application needs. Key advantages include compact size, high efficiency, excellent power-to-weight ratio, and a robust, cost-effective design. Its one-piece tapered pistons with piston rings ensure reliable sealing, while the patented cylinder block drive system guarantees dependable torque transmission.
- Product Introduction
Technical parameters：
Displacement range: 5 to 1000 cm³/rev
Nominal pressure: 400 bar
Peak pressure: 450 bar
The bent-axis axial piston A2FM motor is suitable for both open-circuit and closed-circuit hydrostatic transmission systems.
The output speed is proportional to the input flow rate and inversely proportional to the displacement, while the output torque increases with the pressure differential between the high-pressure and low-pressure sides.
The motor is designed for use in mobile machinery and industrial applications.
A wide range of displacement sizes allows easy matching to various application requirements.
Key features include:
Excellent power-to-weight ratio
Compact overall dimensions
High overall efficiency
Economical and robust design
One-piece tapered pistons with piston rings for reliable sealing
Patented cylinder block drive system ensuring reliable torque transmission
